TND316S-TL-2H

View larger image

Part Number

TND316S-TL-2H

Manufacturer

Description
IC DVR EXPD 25V 1A SOP8
Category
Integrated Circuits (ICs)
Family
PMIC - Full, Half-Bridge Drivers
  • To learn about the specification of TND316S-TL-2H, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
  • To process your RFQ, please add TND316S-TL-2H with quantity into BOM.
  • Omoelec.com does NOT require any registration to request a quote of TND316S-TL-2H.
  • We are offering TND316S-TL-2H for competitive price in the global market, please send us a quote request for pricing. Thank you!
Quick Order
Specifications of TND316S-TL-2H
PackagingTape & Reel (TR)
Output ConfigurationHalf Bridge (2)
ApplicationsDC Motors, General Purpose
InterfaceLogic
Load TypeInductive
TechnologyPower MOSFET
Rds On (Typ)6 Ohm LS, 8 Ohm HS
Current - Output / Channel-
Current - Peak Output1A
Voltage - Supply4.5 V ~ 25 V
Voltage - Load4.5 V ~ 25 V
Operating Temperature-55°C ~ 150°C (TJ)
Features-
Fault Protection-
Mounting TypeSurface Mount
Package / Case8-SOIC (0.154", 3.90mm Width)
Supplier Device Package8-SOIC
