CTX22-15557

View larger image

Part Number

CTX22-15557

Manufacturer

Description
FIXED IND 1MH 1.3A 470 MOHM SMD
Category
Inductors, Coils, Chokes
Family
Fixed Inductors
  • To learn about the specification of CTX22-15557, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
  • To process your RFQ, please add CTX22-15557 with quantity into BOM.
  • Omoelec.com does NOT require any registration to request a quote of CTX22-15557.
  • We are offering CTX22-15557 for competitive price in the global market, please send us a quote request for pricing. Thank you!
Quick Order
Specifications of CTX22-15557
PackagingBulk
TypeToroidal
Material - CoreFerrite
Inductance1mH
Tolerance-
Current Rating1.3A
Current - Saturation-
ShieldingUnshielded
DC Resistance (DCR)470 mOhm Max
Q @ Freq-
Frequency - Self Resonant-
Operating Temperature-20°C ~ 105°C
Frequency - Test100kHz
Mounting TypeSurface Mount
Package / Case10-SMD, Gull Wing
Size / Dimension1.252" L x 1.063" W (31.80mm x 27.00mm)
Height - Seated (Max)0.516" (13.10mm)
Supplier Device Package10-SMT
Other Names513-1659
CTX2215557
